Mec 3072RT - Controls and Switches Troubleshooting

March 2008 "3072RT / 3772RT / 3772RT HD" Service & Parts Manual - ANSI Specifications
Page 4-14
CONTROLS AND SWITCHES
Emergency Stop
Hour Meter
Engine Start
(Green)
Choke/Preheat
(Black)
Circuit Breaker
Gasoline/Propane (Dual Fuel)
Platform /
Chassis
Engine Stop
(Red)
Throttle
(Green)
Lower
(Green)
Raise
(Green)
Engine
Start / Stop
Power Relay
Lift / Drive
Speed / Torque
Emergency Stop
Choke / Glow Plug
Generator (Optional)
Horn (Optional)
Drive Enabled Indicator
(Optional)
Outrigger Extend/Retract
(Optional)
Forward/Up
Rocker Switch
Potentiometer
Reverse/Down
Rocker Switch
Enable Switch
Micro-Switches
Steering
