March 2008 "3072RT / 3772RT / 3772RT HD" Service & Parts Manual - ANSI Specifications
Page 2-6
Battery Replacement
To remove battery, follow these procedures.
BEFORE REMOVING THE BATTERY FROM THE MACHINE, TURN
OFF THE SELECTOR/ KEY SWITCH. THERE SHOULD BE NO
POWER.
Battery is located in the Control Module of the machine.
Always disconnect the negative battery cable first.
Remove bolts holding battery. Lift the battery from the compartment. Put the battery to the side
and dispose of properly.
Prevent damage to battery and/or electrical system;
• Always disconnect the negative battery cable first.
• Always connect the positive battery cable first.
To install battery, reverse the process by positioning the battery in the compartment securely with
hold down bolts. Connect battery cables. Always connect the positive cable first.
