"3072RT / 3772RT / 3772RT HD" Service & Parts Manual - ANSI Specifications March 2008
Page 1-25
BACK
RIGHT
FRONT
LEFT
DRIVE REVERSE
110 - GRY/BLK
HIGH TORQUE
313 - YEL/BLK
HIGH SPEED
213 - YEL/WHT
DRIVE FORWARD
111 - GRY/RED
PROPORTIONAL
333 - PPL/WHT
RIGHT REAR B
LIFT PORT
PRESSURE PORT
- FROM PUMP -
RIGHT REAR A
LEFT REAR B
TO TANK
LOAD SENSE
- TO PUMP -
RIGHT FRONT A
LEFT FRONT B
RIGHT REAR B
LEFT REAR A
LEFT FRONT A
BRAKE
MANUAL VALVE
FOR BRAKE
RELEASE
HAND PUMP
BRAKE RELEASE
STEER RIGHT
107 - ORG/WHT
STEER LEFT
108 - GRN/RED
STEER RIGHT
STEER LEFT
LIFT
204 - RED/BLU
GAUGE PORT
