Mec 3072RT - Page 72

March 2008 "3072RT / 3772RT / 3772RT HD" Service & Parts Manual - ANSI Specifications
Page 4-2
BACK
RIGHT
FRONT
HYDRAULIC MANIFOLD
DIAGNOSTIC LEDs
LEFT
DRIVE FORWARD
111 - GRY/RED
LIFT
204 - RED/BLU
GAUGE PORT
DRIVE REVERSE
110 - GRY/BLK
HIGH TORQUE
313 - YEL/BLK
HAND PUMP
BRAKE RELEASE
STEER RIGHT
107 - ORG/WHT
HIGH SPEED
213 - YEL/WHT
TO TANK
LOAD SENSE
- TO PUMP -
RIGHT FRONT A
LEFT FRONT B
RIGHT REAR B
LEFT REAR A
LEFT FRONT A
BRAKE PORT
COUNTERBALANCE
VALVES
PULL VALVE
BRAKE RELEASE
STEER RIGHT
STEER LEFT
PROPORTIONAL
333 - PPL/WHT
RIGHT REAR B
LIFT PORT
LIFT RELIEF
RV1
STEER RELIEF
RV2
PRESSURE PORT
- TO PUMP -
RIGHT REAR A
LEFT REAR B
STEER LEFT
108 - GRN/RED
