Page 30 65-J Diesel - Operator’s Manual
September 2022Section 7 - Operating Instructions & Pre-Operation Function Tests
ART_4747
Upper Control Box
Drive & Steer Directional Arrows
Platform over non-steering wheels
Platform over steering wheels
Decals
Decals
When the platform is over the steering wheels,
the machine moves in the opposite direction
of the Control Lever.
Pay careful attention to the
Chassis Drive & Steer arrows
for machine direction.
Speed/Torque Switch
Move this switch to the left for high speed drive. Move this switch to the right
for high torque drive.
