Page 16 92RT Scissor Lifts - Operator’s Manual
July 2020Section 6 - Function Tests and Operating Instructions
IMPORTANT Check that the route of travel to be taken is clear of persons, obstructions, debris,
holes, and drop offs, and is capable of supporting the machine.
Select PLATFORM Operation
Lower Control Box: Turn the selector switch to PLATFORM.•
Operate from Platform
Hold switch in upper position until engine starts. Release when engine
starts.
•
If equipped, press the Horn Button to verify proper operation.•
Overload Light
Light ON indicates too much weight on the platform.
An audible alarm will sound and all machine function will stop.
Remove weight from the platform to restore function and continue.
•
•
•
Emergency Stop
Press the EMERGENCY STOP switch at any time to stop all machine
functions.
Turn switch clockwise to reset.
•
•
Activation of the EMERGENCY STOP switch will apply brakes
immediately. This may cause unexpected platform movement as the
machine comes to a sudden stop. Brace yourself and secure objects on
the platform during operation of machine.
ART_2363
Steer
Enable
Bar
Proportional
Joystick
Lower
Lift
Forward
Reverse
Joystick Operation
Function speed is proportional and is controlled by the movement of the
Joystick.
The further it is moved forward, the faster the speed will be.
The Joystick returns to the neutral (center) position when released.
•
•
•
