12.0 Technical specications
This device complies with Directive 93/42/EEC:
Class II a.
Classification in accordance with EN 60601-1: II
Type B
IP 20 (device)
IP 20 (power-supply unit)
IP 22 (pedal)
Device for intermittent operation: 60” ON 30” OFF with irrigation.
30” ON 120” OFF without irrigation.
Voltage required by the external power-supply unit:
Mectron - Model AC/DC adapter
- from 100 to 240 Vac ± 10 % 50/60 Hz.
Voltage required by the device: 33 VDC ± 10 %
Max. power absorbed: 40 VA
Internal fuse: Type 5 X 20 mm 1 X 2 A T.
Working frequency: Automatic scanning. From 24 to 29.5 KHz.
Power: Adjustable in 9 pre-set steps:
From 1 to 2 ENDO
From 3 to 5 PERIO
From 6 to 9 SCALER
Output of the peristaltic pump: Adjustable in 10 steps from 0 to 9
From 25 to 55 ml/min approx.
Safety devices and time to tripping of the APC circuit:
- No handpiece connected
Tripping time 20 ms.
- Cord interrupted
Maximum tripping time 80 ms.
- Insert broken or not correctly tightened
Three scans, 150 ms each
- Protection by discharge to earth
Tripping time 20 ms
Alarms: A warning appears on the front-panel display
Se sections:
”Safety and alarm circuits”
“Troubleshooting”
Operating conditions: From +10°C to +40°C.
Relative humidity from 30% to 75%.
Transport and storage conditions: From -10°C to +70°C.
Relative humidity from 10% to 90%.
Air pressure P: 500hPa/1060hPa
Weight and measurements: 0.92 Kg
L - W - H 228 x 146 x 146 mm
12.1 Electromagnetic compatibility EN 60601-1-2
Guidance and manufacturer’s declaration - Electromagnetic emissions
The PIEZO SMART is intended for use in the electromagnetic environment specified below.
The customer or the user of the PIEZO SMART should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment - Guidance
RF emissions
CISPR 11
Group 1 The PIEZO SMART uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B The PIEZO SMART is suitable for use in all establishments,
including domestic establishments and those directly connected
to the public low-voltage power supply network that supplies
buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations / flicker
emissions
IEC 61000-3-3
Complies
