Medivators SCOPE BUDDY - System Components

SCOPE BUDDY USER/SERVICE MANUAL
10
System Components
• SCOPE BUDDY Base Unit
• Wall-mount bracket
• Power Supply
• Fluid Intake Line
• DSD Extension Line
• Universal Cleaning Adapter Extension Line
• Universal Cleaning Adapter 2-way adapter
• Universal Cleaning Adapter 3-way adapter
• Universal Cleaning 4-way adapter
• Flow Verification Tube
• Elevator Wire Channel (EWC) Hookup
Figure 1 System Components
SCOPE BUDDY Base Unit
Wall-Mount Bracket
Power Su
pp
l
y
Fluid Intake Line
DSD Extension Line
UCA 3-wa
y
Ada
p
ter
UCA 4-wa
y
Ada
p
ter
UCA 2-wa
y
Ada
p
ter Universal Cleanin
g
Ada
p
ter Extension Line
Flow Verification Tube
Elevator Wire Channel Hook-u
p
