MegaCut (2D) software
MegaCut (2D) software
The MegaCt (2D) software is suitable for precise tooling of any 2D shapes. It also supports
multi-layer drawings for tooling at different depths. It allows for both through cuts as well as
surface engraving. When cutting through a material, it is possible to use a spiral cut and a polishing
operation. Thanks to a lining operation, it is possible to cut out the insides of a shape. The cutting
tool diameter can be calculated in the tooling process and the tool can go on the inside of a shape,
on the outside or along the center of the cutting line.
Thanks to Gcod support, MegaCut 2D allows for tooling in 3 axes as well.
The preparation of a drawing for MegaCut 2D is done in a graphics softare. MegaCut 2D accepts
the following formats: PLT (CorelDraw), DXF (AutoCad) or NC (postprocesor – Gcod). Once a
drawing is loaded in the MegaCut software it is possible to scale it to the required size. Thanks to
the simulation feature, it is possible to preview on the PC screen the exact tooling sequence prior to
starting the actual cut.
Machine start-up procedure
Machine start-up procedure
When turning on the machine, please always follow this sequence of steps:
• turn the electronic controller on (turn the red main switch clockwise)
• turn on the spindle cooling pump
• turn on the PC
• ensure the proper controller-PC connection (controller display should read Ready, USB
connected; if it says USB disconnected it means the PC failed to recognise the machine
properly)
• start MegaCut software
Possible problems in controller-PC communication are explained in the following section: Błąd:
Nie znaleziono źródła odwołania.
Software settings
Software settings
Language version
At the moment, MegaCut 2D is available in the following languages: Polish, English, Italian and
Slovakian. The application always attempts to start up in the same language version as your PC OS.
If not available, it defaults to English.
Should you require MegaCut software in any other language, please do not hesitate to contact
www.megaplot.com phone: +48 693 707 575 office@megaplot.com
