Lining algorithms
Lining algorithms
This description applies to the lining operation available under Functions - Lining in MegaCut.
1. There are four basic types of lining:
◦ vertical (HPATTERN_VERTICAL)
◦ horizontal (HPATTERN_HORIZONTAL)
◦ forward slash (HPATTERN_FORWARD_SLASH)
◦ back slash (HPATTERN_BACK_SLASH)
