Megger LTW425 - Top Panels

7
2.3 Top panels
LCD Display
Setup function
select
Test button
Backlight
On/Off
Test lead connections
See section 2.5
Loop test function:
(all except LTW315)
Z
MaxZ
R1+R2
Zref
Neck strap
slots
Range selector:
NO-TRIP
High Current
HIGH Res (LTW425)
Volts/Frequency
Setup
Front panel cover
(folded under instrument)
PFC display
key
