2.5 Connection panel
2.6 Lid open/closure
1. Open lid by lifting up front panel tab (1).
2. Foldaway underneath instrument (2 & 3) and push into retaining slot (4).
Single or 3 Phase
connection
Earth, Neutral or 2
nd
phase
connection
Warning
Read user guide
Maximum 300V
Phase to earth
USB connection to
computer port
LTW335 only
