Meiko EcoStar 545D - Operating Panel and Controls

9625762 14 / 44
IMPORTANT!
• Only of automatic hood
Climbing alongside the washing machines while they are in operation is prohibited.
The same applies when cleaning the washing machines.
7.1 Operating panel
Illustration 1; Operating panel
Program start key
Program is running
appliance is switched on
Program is running
“Off” key
Temperature display tank / boiler,
Fault display
Information display
Code display
Of automatic hood
Open-close hood key.
