Operating instructions Glass-, dish- and utensilwashing machine
M-iClean U
Technical data
9712938 22 / 68
Design and construction subject to change without prior notice!
5.7.2 Thermolabel control
In a way which is similar to A
0
control, machines with Thermolabel control have a
disinfection process which uses moist heat. The dishwashing machine heats the
rinse water to a higher temperature in order to eliminate germs. The efficacy of the
disinfection can be tested using a measurement strip, the Thermolabel. The meas-
urement strip changes colour after 4 seconds at 71 °C for a wash item.
• During washing the tank temperature is heated up to 71° C and maintained at
that temperature.
• The rinsing process runs until the end of the set programme runtime, but at
least until the temperature value is reached. After this comes a pause for drain-
ing and the final rinse.
• Washing at high temperatures and long spells in the wash tank can lead to
glass corrosion and premature wear to decoration.
6 Technical data
MEIKO has created a dimensional drawing that shows machine dimensions as well
as connection and consumption values.
Further data should be taken from the MEIKO dimensional drawing.
Machine weight
Equipment Basic machine Basic machine Basic machine
Versions + GiO in the base + GiO separate
M-iClean US 56 kg 63 kg 80 kg
M-iClean UM 63 kg 82 kg 87 kg
M-iClean UM+ 74 kg 93 kg 98 kg
M-iClean UL 77 kg 96 kg 101 kg
Noise emissions
Work place noise level LpA ≤ 70 dB
Water pressure
The water pressure for the fresh water supply before the solenoid valve must be in
the following pressure range:
– Machines without GiO module: 0.6 - 5 bar
– Machines with GiO module: 1 - 5 bar
• If the minimum pressure flow is too low, increase the pressure using a booster
pump.
• If the maximum pressure is exceeded, limit the pressure using a pressure regu-
lator.
