15.5 Assignment list
View inputs/control outputs
Display
Input/output/other Conditions
Left
Right
In
1
0/1
Door closed
None
In
2
0/1
Boiler level
none
In
3
0/1
Leakage detector switch - floor
none
In
4
0/1
Not occupied
none
In
5
0/1
Not occupied
none
In
6
0/1
Not occupied
none
In
7
0/1
ADT impulse sensor (vacuum dosing)
none
In
8
0/1
Not occupied
none
In
9
0/1
Not occupied
None
In
10
0/1
Not occupied
None
In
12
0/1
Not occupied
None
In
13
0/1
Threshold tank level 1
None
In
14
0/1
Threshold tank level 2
None
In
15
0/1
Threshold tank level 3
None
In
16
0/1
Tank level 4 (Option)
None
In
17
0 .. 255
Without function
None
In
18
0 .. 255
Without function
None
In
19
Xxx
Boiler temperature in °C or °F
None
In
20
Xxx
Tank temperature in °C or °F
None
In
21
Xxx
Tank level (1 mm unit)
None
In
22
0 .. 255
Without function
None
Ou
1
0/1
Wash pump
No leak water
Ou
2
0/1
Booster pump
No leak water
Ou
3
0/1
Drain pump
No leak water
Ou
4
0/1
Rinse aid dosing pump
No leak water
Ou
5
0/1
Detergent dosing pump/ADT valve
No leak water
Ou
6
0/1
Indication of operation
No leak water
Ou
7
0/1
Filling valve
No leak water
Ou
8
0/1
SASm soft starter system
No leak water
Ou
9
0/1
Boiler heating
No leak water
Ou
10
0/1
Tank heating
No leak water
Ou
11
0/1
Not occupied
None
Ou
12
0/1
Not occupied
None
Leak water switch condition: Leak water switch must not have operated.
