Melitta CI TOUCH F630-101 - Overview of the appliance; The appliance at a glance

Overview of the appliance
31
GB
1 Overview of the appliance
1.1 The appliance at a glance
1
3
5
6
7
8
9
10
2
4
Fig. 1: Front left of the appliance
13
14
15
16
18
17
12
11
Fig. 2: Front right of the appliance
1 Water tank
2 ON/OFF button
3 2-chamber bean container
4 Bean Select
5 Ground coee chute
6 Cup tray with stainless steel plate
(depending on the model)
7 Control panel
8 Height-adjustable outlet with 2 coee
nozzles, 2 milk nozzles,
1 hot water nozzle, cup illumination
9 Coee grounds container (inner)
10 Drip tray
11 Milk hose connection at the outlet
12 Cover
13 "Grinding neness adjustment" lever
(on the rear side)
14 Power cable with cable insert compart-
ment
15 Brewing unit (behind the cover)
16 Milk hose connection to the drip tray
17 Cup plate
18 Float
