Rev 3.4
Mellanox Technologies
54
Table 11 - IS5030 Specification Data
Physical Power and Environmental
Size:
IS5030-B (short)
IS5030-S
(Standard i.e. long)
Weight:
Short:
Standard:
Mounting:
Air Flow:
SerDes Speeds:
Connector Types:
1.716” (1U) H x 17.17” W x16.84”
D
43.6mm X 436.2mm X 427.7mm
1.716” (1U) H x 17.17” W x24.71”
D
43.6mm X 436.2mm X 627.7 mm
15.3 lbs. 6.94kg 1 PSU
17.2 lbs. 7.80kg 2 PSUs
19.71lbs. 8.94kg 1 PSU
21.6lbs. 9.797kg 2 PSUs
19” Rack mount
94.0 CFM
10, 20, or 40,Gb/s per port
QSFP
Input Voltage:
Power Consumption:
405EXR management
Passive cables:
Active cables:
QSFP Max
Power per port for
active cables:
Temperature:
Humidity:
Shock and
Vibration:
100 - 240 VAC 50-60Hz
Typical / Max in W
118.30 / 147.46
190.59 / 243.86
For second power supply
add 7.6 W
2.0W
10° to 45° Celsius
10% - 90% non-condensing
ETSI EN 300 019-2-2:
1999-09
Protocol Support Regulatory Compliance
InfiniBand:
QoS:
Management:
Data Rate:
Auto-Negotiation of (40Gb/s,
20Gb/s, 10Gb/s)
8 InfiniBand Virtual Lanes for all
ports
Baseboard, Performance, and
Device management Agents for full
InfiniBand In-Band Management
QDR
Safety:
EMC (Emissions):
Environmental:
Acoustic:
Sound power level:
US/Canada: cTUVus
EU: IEC60950
International: CB
USA: FCC, Class A
Canada: ICES, Class A
EU: EN55022, Class A
EU: EN55024, Class A
EU: EN61000-3-2, Class
A
EU: EN61000-3-3, Class
A
Japan: VCCI, Class A
EU: IEC 60068-2-64: Ran-
dom Vibration
EU: IEC 60068-2-29:
Shocks, Type I / II
EU: IEC 60068-2-32: Fall
Test
ISO 7779
ETS 300 753
76 dB(A)
