ConnectX®-3 Pro Ethernet Single and Dual QSFP+ Port Adapter Card User Manual Rev 1.7
Mellanox Technologies
10
1 Introduction
This is the User Guide for Mellanox Technologies Ethernet adapter cards based on the Con-
nectX®-3 Pro EN integrated circuit device. These adapters connectivity provide the highest per-
forming and most flexible interconnect solution for PCI Express Gen3 servers used in Enterprise
Data Centers, High-Performance Computing, and Embedded environments.
This chapter covers the following topics:
• Section 1.1, “Product Overview,” on page 10
• Section 1.2, “Features and Benefits,” on page 11
• Section 1.3, “Operating Systems/Distributions,” on page 12
• Section 1.4, “Connectivity,” on page 12
1.1 Product Overview
The following section provides the ordering part number, port speed, number of ports, and PCI
Express speed. Each adapter comes with two bracket heights - short and tall.
Table 3 - Single and Dual-port 40/56 Gigabit Ethernet Adapter Cards
Ordering Part Number (OPN)
MCX313A-BCCT - single-port card
MCX314A-BCCT - dual-port card
Data Transmission Rate
40/56 GbE
Number of ports
MCX314A-BCCT - dual-port QSFP+
MCX313A-BCCT - single-port QSFP+
PCI Express SERDES Speed
PCIe 3.0 x8 8GT/s
RoHS
R6
Adapter IC Part Number
MT27528A0-FCCR-FV
Device ID (decimal)
4103 for Physical Function
4100 for Virtual Function
