ConnectX®-3 Pro Ethernet Single and Dual QSFP+ Port Adapter Card User Manual Rev 1.7

Mellanox Technologies

A.3 I

C-compatible Connector Pinout

Figure 13: Compatible Connector Plug and Pinout

Connector Pin Number Signal Name

1SPSDA

2SPSCL

3 GND

4NC

5NC
