PERFECT page 38
18. Memory card: MEMoryCardXL
A temperature programme with up to 40 ramps can be programmed on the MEMoryCardXL. Programming
can take place directly on the controller or through the PC program “Celsius 2005”.
For improved clarity it is recommended that extensive programmes are prepared graphically on the PC.
Where a MEMoryCardXL is programmed, it can be read only on the same oven type for which it has been
programmed.
Marking:
The text field of the MEMoryCardXL can be marked
individually with text or diagram
18.1 Programming the MEMoryCardXL from the oven
Insert the MEMoryCardXL into the slot in the control panel field.
The selected settings are written directly to the card and stored on it. After the card has been removed, the
programme stored internally in the controller becomes again activated.
18.2 Programming the MEMoryCardXL from a PC with the oven
Link the PC to the oven with an interface cable via the serial interface (see Section: „Communication
interface“). Insert the MEMoryCardXL into the input slot in the control panel field.
Write protection:
The Memory Card XL can be provided with write protection using the PC program “Celsius 2005”. The
programme on the card can then not be altered on the controller.
18.3 Programming the MEMoryCardXL from a PC using the read-write unit
Using a read-write unit (which can be purchased separately) the MEMoryCardXL can be programmed
from a PC with “Celsius 2005” without any connection to an oven. It is important to ensure that the
MEMoryCardXL has to be inserted with the contact field pointing upwards towards the marking of the
read-write unit.
