Then push MEM to enter EDIT MODE: use button MENU/<< to
change numbers and button >> to change digit. The blinking
digit identifies the digit that can be edited.
When the required temperature has been set, press button
MEM to save changes or press button VIEW to discard
changes.
The temperature alarm can be set between 0 and 1999
degrees.
When the system displays a temperature greater than the alarm
value, the temperature on the display will begin flashing. When
the thermocouple temperature falls below the alarm value, it will
cease flashing.
Max RPM
value
This function sets the maximum scale for the graphical RPM
display and the maximum acceptable RPM value captured by
MyChron 3.
MyChron 3 has five levels for the maximum RPM : 8,000 /
10,000 / 12,000 / 16,000 / 20,000 RPM / 22,000 / 25,000 RPM.
To run this function, after having entered the CONFIGURATION
MODE, push MENU/<< till when you don’t see
MAX RPM VALUE
Then push MEM to enter EDIT MODE and use buttons
MENU/<< or >> to scroll between the five standard RPM
values. When the required RPM value is displayed, press
button MEM to save the changes or button VIEW to quit.
27
