Serial Port and User Equipment Connections
Memotec Inc. 5-7
Ordering part number 161-0896-001, Stock number 502-0943-006.
5.5.4 X.21 EU Cables
NOTE: An X.21 EU cable has a metric M3 screw on the DB-15 connector.
• HD-26 male connector at one end for connection to the NetPerformer serial port
• DB-15 female (DCE) or male (DTE) connector at the other end for connection to
the X.21 equipment
- Use the DCE female cable for connection to a male connector on the X.21 EU
equipment (typically a DTE device)
Ordering part number 161-0904-001, Stock number 502-0951-006.
- Use the DTE male cable for connection to a female connector on the X.21 EU
equipment (typically a DCE device)
Ordering part number 161-0903-001, Stock number 502-0950-006.
5.5.5 TIA-449 (V.36) Cables
• HD-26 male connector at one end for connection to the NetPerformer serial port
• DB-37 female (DCE) or male (DTE) connector at the other end for connection to
the TIA-449 (V.36) equipment
- Use the DCE female cable for connection to a male connector on the TIA-449
(V.36) equipment (typically a DTE device)
Ordering part number 161-0901-001, Stock number 502-0948-006.
- Use the DTE male cable for connection to a female connector on the TIA-449
(V.36) equipment (typically a DCE device)
Ordering part number 161-0902-001, Stock number 502-0949-006.
5.5.6 TIA-530 Cables
• HD-26 male connector at one end for connection to the NetPerformer serial port
• DB-25 female (DCE) or male (DTE) connector at the other end for connection to
the TIA-530 equipment
- Use the DCE female cable for connection to a male connector on the TIA-530
equipment (typically a DTE device)
Ordering part number 161-0899-001, Stock number 502-0946-006.
- Use the DB-25/DTE male cable for connection to a female connector on the
TIA-530 equipment (typically a DCE device)
