SDM-9XXX Series Hardware Installation Guide
4-4 Memotec Inc.
4.3 Optional Hardware
NOTE: The third interface card slot is not available on the SDM-9220.
On the NetPerformer console, the ports are identified as follows:
Item Details
DSP module: low or high-density “DSP Modules” on page 4-13
Interface cards: FXS (dual or quad port), FXO (dual
or quad port), E&M/PTT (quad port), T1/E1 (single
or dual port), ISDN-BRI S/T (dual port, SDM-9220/
9230 only), Serial (dual port, SDM-9220/9230 only)
“Interface Cards” on page 4-15
Table 4-3: Optional Hardware
Physical Port Port Number on Console (LINK)
Slot 1, digital port 1 100
Slot 1, digital port 2 150
Slot 2, digital port 1 200
Slot 2, digital port 2 250
Slot 3, digital port 1 300
Slot 3, digital port 2 350
ETHERNET (top) ETH1
ETHERNET (bottom) ETH2
SERIAL PORT 1
CONSOLE CSL
Table 4-4: List of physical ports and their port numbers
