85-03-01071 D30 DEEP TIMBER Page 17
D30 DEEP TIMBER Fireplace insert Ratings Information
This Mendota Insert must be installed in an existing Masonry Wood Burning Fireplace insert or a Factory Built ZC Wood Burning
Fireplace insert.
MINIMUM FIREPLACE INSERT CAVITY SIZE REQUIREMENT: 30-1/2” WIDE X 19” HIGH X 16-1/2” DEEP (depth can be reduced
using a surround with a deep outer edge finish).
ELECTRICAL REQUIREMENTS: 120 Volts AC, 1.5 Amps (minimum line voltage allowed 110 Volts AC) REQUIRED GAS SUPPLY
PRESSURE: NAT. GAS: 7" W.C. [5.0" W.C. MIN., 11" W.C. MAX.]
L.P. GAS: 11" W.C. [11" W.C. MIN., 13" W.C. MAX.]
LP GAS CONVERSION KIT: This Insert comes configured for use with Natural Gas. To convert the Insert for use with LP Gas,
install: LP GAS CONVERSION KIT HA-58-00302.
GAS INPUT RATES High Fire Low Fire
BTUH .......................... NAT. GAS 30,000 19,900
BTUH .......................... L.P. GAS 29,000 16,200
ORIFICE SIZES………… Natural Gas #35; LPG #52
P.4 EFFICIENCY ..........78.6%
FLUE VENTING ............1. CO-LINEAR - 4” DIAMETER EXHAUST & 4” DIAMETER AIR INLET APPROVED VENTS, 10 Feet Minimum
Vent Length. 50 Feet Maximum Vent Length.
2. COAXIAL – 4” DIAMETER EXHASUT & 6” DIAMTER AIR INLET APPROVED VENT, 10 Feet Minimum Vent
Length. 50 Feet Maximum Vent Length.
WARNING: Low-profile vent caps offered by any brand are not approved for use with Mendota Gas Inserts.
NET WEIGHT................175 lbs. (Team Lift recommended)
BARRIER SCREEN: A barrier screen that has been certified for use with this insert must be installed on the Insert when it is in
use. The barrier screen will prevent accidental contact with the glass door face, which could result in a severe burn.
SAFETY: AGA certified, standing pilot system with thermocouple safety.
CERTIFIED TO: ANSI Z21.88– 2016
This Mendota Gas Fireplace Insert has been tested and certified by:
Intertek Testing Services, 8431 Murphy Drive, Middleton, WI 53562
