85-03-01071 D30 DEEP TIMBER Page 73
6.8 REPLACEMENT PARTS INFORMATION
How to Access Components
The descriptions below show where the main fireplace inserts components are located and how to access them for service. The
descriptions show how to access the components after the fireplace insert has been installed.
Pilot: The pilot light is located on the left side inside the firebox.
Gas Valve: The main gas valve is located behind the lower grill and beneath the firebox.
Complete Valve Assembly: To make working on components easier, this fireplace insert has been designed with the valve, pilot,
shutter boxes, shutter cables and gas lines as part of one assembly that can be removed from the fireplace insert. To remove the
assembly first remove burners and burner airbox. After disconnecting the gas line and wires, below the firebox, remove hex nuts
that secure the valve mounting plate to firebox floor. Lift up and remove the entire assembly from the firebox.
Convection Blowers: The convection blowers are mounted in the space below the firebox, behind the gas valve. To access the
convection blowers, remove the Valve Assembly first.
General Replacement Parts List
