Mendota D30 - Valve Assembly Replacement Parts

85-03-01071 D30 DEEP TIMBER Page 74
Convection Air Blower System Parts
Item 1
15-02-00120
BLOWER, RH
Item 2
15-02-00121
BLOWER, LH
Figure 6-3 D30 DEEP TIMBER BLOWER ASSEMBLIES
Valve Assembly Replacement Parts
Item 1
65-14-00035
NG Orifice, #35
Item 2
65-14-00052
LPG Orifice, #52”
Item 2
05-04-00035
Pilot Assembly, 3-way hood
Item 3
65-06-01064:1
Spark Ignitor
Item 4
05-02-00313
Main Gas Valve
Figure 6-4 Valve Assembly Replacement Parts
