85-03-01071 D30 DEEP TIMBER Page 75
Glass Frame Parts Replacement Procedure
WARNING: do not use substitute materials. All replacement materials must be certified and obtained through
Mendota fireplace inserts.
TO REPLACE DAMAGED GLASS
1. DRILL RIVETS USING 1/8" DRILL BIT.
2. REMOVE 3 RIVETS EACH SIDE & BRACKETS.
3. REMOVE GLASS FROM FRAME.
4. REMOVE AND DISCARD OLD GASKET.
5. INSTALL NEW GASKET ON GLASS EDGES.
6. PLACE GLASS IN FRAME.
7. REPLACE RETAINER BRACKETS AND SECURE WTH NEW RIVETS
The glass frame assembly and its individual components are available through Johnson Gas Appliance Company. Contact your
dealer for more detailed ordering information.
