Mendota D30 - Leveling Bolts Installation

85-03-01071 D30 DEEP TIMBER Page 70
Leveling Bolts Installation
Perform this step after you have measured the firebox floor for level surface characteristics. Tip the Insert body on its back on
the wooden pallet. Thread one leveling bolt in to each leveling bolt receiving fastener. Thread the bolt in as far as necessary to
achieve the leveling effect desired.
Figure 4-4 Leveling Bolts Installation
