14 | Page
INNER FINISHING
GUIDES(TOP, L &R)
OUTER FINISHING
GUIDES (TOP, L & R)
FRAMING DEPTH and FINISHING GUIDES
The framing depth for this fireplace
is 19-1/2 inches. This is a fixed
depth required for all installations,
except a corner installation and for
installations that use solid Granite
or Marble slabs as fascia materials.
For corner installations, see figures
1 and 4.
For installing solid Granite or Mar-
ble slabs as fascia material, reduce
WKHIUDPLQJGHSWKE\ò´WKHQLQVWDOO
ò´WKLFNGU\ZDOORQWKHIUDPLQJ
studs so that the drywall is flush
with the front face of this fireplace.
Install the Granite or Marble slab so
that it adheres to the face of the
fireplace and the drywall.
Finishing Guides
Two sets of Finishing Guides are
supplied with this fireplace: One set
is called the Outer Guide and the
other set is caOOHGWKH,QQHU*XLGH%RWKJXLGHVSURWUXGHRXW´IURPWKHIDFHRIWKLVILUHSODFH%RWKJXLGHVDUHIDFWRU\Ve-
FXUHGXVLQJVFUHZVDQGPD\EHUHPRYHGLIQRWQHHGHGRUPD\EHSHUPDQHQWO\DWWDFKHGXVLQJ´ULYHWVWKDWDUHVXSSOLHG
with this fireplace.
Inner Guide:
Identify the Inner Finishing Guides (Top,
Left and Right). These guides should be used as a
guide for finishing materials if you are planning to in-
stall WKLVILUHSODFHDVD³)8//9,(:´ZLWKRXWDQ\Ge-
corative front or if you are planning to install a
³%28/(9$5''225.,7´³'8&+(6667$,1('
*/$6629(5/$<´³32575$,7*/$66)5$0(
29(5/$<´or a ³6(5(1$'(*/$66)5$0(
29(5/$<´. Remove and discard the Outer Guides
(Top and sides) if you plan to use the Inner Guides.
Outer Guide:
Identify the Outer Finishing Guides (Top, Left and Right). These guides should be used as a guide for fi-
QLVKLQJPDWHULDOVLI\RXDUHSODQQLQJWRLQVWDOOD³+20(67($'´ or ³:,//2:´GRRUNLWRQWKLV fireplace. Remove and dis-
card only the Inner Guides (Top and Sides only) if instalOLQJD³:,//2:´RU³+20(67($'´GRRUNLWDQG\RXSODQWRXVH
the Outer guides.
FV-41 DECORATIVE FRONTS
-FINISHING GUIDES SELECTION-
-WILLOW-
USE
OUTER GUIDE
-HOMESTEAD-
USE
OUTER GUIDE
-BOULEVARD-
USE
INNER GUIDE
-DUCHESS-
USE
INNER GUIDE
-SERENADE-
USE
INNER GUIDE
-PIONEER-
USE
INNER GUIDE
DECORATIVE FRONT TYPE INNER GUIDE
OUTER GUIDE
FULL VIEW/ NO FRONT USE
DISCARD
BOULEVARD DOOR KIT USE
DISCARD
DUCHESS OVERLAY USE
DISCARD
SERENADE OVERLAY USE
DISCARD
PORTRAIT OVERLAY USE
DISCARD
WILLOW DOOR KIT DISCARD
USE
HOMESTEAD DOOR KIT DISCARD
USE
