85-03-01120 M27 Page 43
Factory Installed Manual Gas Shutoff Valve
A manual gas shutoff valve is factory installed and located in the left-side above the main gas valve. To operate the manual gas
shutoff, open left side door to expose controls. Located manual gas shutoff handle. Rotate clockwise to shut off gas flow or
counter-clockwise to turn on gas flow.
Gas Inlet Fittings Information
Caution: Before you run the gas line, read, understand and properly calculate the required gas line size.
Improper (too small) gas line size application can lead to improper burner ignition and can cause property
damage and/or injury. If you are not qualified or certified to run a gas line, do not proceed. Contact a
qualified Gas Plumber.
The gas inlet fitting supplied with this Fireplace provides a 1/2” female NPT fitting. This requires you to supply a ½” NPT male
fitting for connection to this appliance.
Based on the gas line size you have selected use an appropriate NPT fitting to adapt and connect to the 1/2” male NPT end
adapter.
