85-03-01120 M27 Page 94
6.7 BURNER FLAME HEIGHTS REFERENCE DIAGRAM
This image provides a visual reference for the
burner flames burning at maximum height after
the burners have been operating for 30
minutes or longer. A normal rear flame will be 1
to 2 inches above the rear log top edge. This,
however, is dependent on the gas type, air
shutter opening setting and vent system
configuration. Actual flame heights can be
slightly higher or lower when compared to this
reference image.
