85-03-01120 M27 Page 88
Main burner should now light IMMEDIATELY and flame should not "lift" off burner after 5 minutes of initial
startup. If there is any delay in ignition or if flame is "lifting off" burner after 5 minutes, turn off burner
and carefully check for proper installation of logs/coals, vent system and proper pilot flame impingement on
burner and thermopile. Logs or coals must not block pilot flame or main burner flame. Vent system must
be leak proof.
DO NOT PROCEED WITH OPERATION UNLESS BURNER "CYCLES" ON/OFF WITHOUT DELAYS!
13 To reduce heat output, turn Hi/Lo Knob counterclockwise to reduce flame height and heat output. Blower speed can also
be turned down to reduce heat distribution.
NEVER “over fire" by increasing BTUH above nameplate specifications.
NEVER turn down (reduce) pilot flame below the minimum 325 millivolts.
14 Open windows for first two hours of operation.
NOTICE: Initial start-up will cause some NON-TOXIC "off gassing" of adhesives, binders, paint, etc. Most
nuisance odors will be
eliminated after the first 2 hrs. of operation, however, slight amounts may be present during the first 24
hrs.
5.5 TO TURN OFF GAS TO FIREPLACE
1. Toggle the MAIN BURNER ON/OFF button to OFF.
2. Turn Gas Cock Dial clockwise to "PILOT” then to “OFF” position.
3. Turn off the internal manual shutoff valve in the appliance.
4. Turn OFF the external manual shutoff valve if one was required and supplied by installer and mounted adjacent to fireplace.
5. Turn OFF all electric power to the fireplace if service is to be performed.
