Page 98 – Operator's manual
Menzi Muck A111E
If when driving in „normal“ mode the safety controller is active and „driving“ is switched off, the
vehicle will brake over a ramp to prevent it from stopping too quickly.
Memory index
Error code
(255 = no error))
Error code
(255 = no error)
Working hydraulics
Driving active
Trouble shooting
0 130 Accelerator j n Accelerator depressed at switch-on
0 12 Accelerator n n
n
n
Accelerator potentiometer defective
Potentiometer short circuit to earth or +24V
Neutral switch defective
1 Limiter potentiometer V max No diagnosis possible
2 Speed potentiometer V max No diagnosis possible
7 8 Diesel speed sensor Sensor short circuit or interrupt
10
4 Battery voltage Voltage < 20V
10
3 Battery voltage Voltage > 30V
11 4 Supply voltage to sensors +
Potentiometer
j n Voltage < 7.5V
Short circuit to earth
3 Supply voltage to sensors +
Potentiometer
j n Voltage > 8.5V
short circuit to +24V
12 12 Brake solenoid n n On: short circuit to earth or interrupt
Off: short circuit to +24V
13 12 Operating pump solenoid Short circuit / interrupt
14 12 Drive solenoid forwards n n Short circuit / interrupt
16 12 Release valve n n On: short circuit to earth or interrupt
Off: short circuit to +24V
17 12 Drive solenoid back n n Short circuit / interrupt
18 12 High pressure gear (Powermode) Short circuit to +24V when On
Interrupt when Off
24 13 EEPROM j n Incorrect version number
25 13 CAN Bus CAN line defective / DCE or ECU Off
29 8 Idling gas reset button j j Press > 10 seconds
30
12 Fine mode solenoid j j Short circuit / interrupt
31 8 Power Mode button j j Press > 10 seconds
