Clamp Bracket Components (Power Tilt)
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Carrying handle
2 3 Grease fitting
3 2 Screw (M6 x 16) 6.0 53.1 –
4 2 Anode
5 1 Starboard clamp bracket
6 4 Bushing
7 2 Washer
8 2 Screw (M8 x 20) 13 115 –
9 2 Cap
10 1 Tilt tube assembly
11 2 Locknut (M8) 13 115 –
12 2 Washer
13 1 Ground wire (starboard clamp bracket to swivel bracket)
14 3 Screw (M6 x 12) 6.0 53.1 –
15 2 Tilt lock pin 13 115 –
16 2 Nylon washer
17 1 Washer
18 1 Screw (M6 x 12) 6.0 53.1 –
19 1 Upper pin
20 1 Spring pin
21 1 Washer
22 2 Collar
23 1 Swivel bracket
24 2 Bushing
25 1 Bushing
26 1 Lower pin
27 1 Power tilt assembly
28 1 Ground wire (port clamp bracket to power tilt assembly)
29 2 Cable tie
30 1 Spring
31 1 Tilt lock lever
32 1 Grip
33 1 Port clamp bracket
34 1 P‑clip
35 1 Screw with washer (except ProKicker models)
36 1 Nut 24.0 – 17.7
37 4 Nut 13.5 120 –
38 8 Washer
39 4 Transom screw
40 2 Stepped collar (ProKicker models)
41 2 Strap (ProKicker models)
42 2 Screw (M6 x 25) (ProKicker models) 6.0 53.1 –
43 2 Washer (ProKicker models)
44 2 Collar (ProKicker models)
45 2 Large washer (ProKicker models)
Clamp/Swivel Bracket and Driveshaft Housing
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 5A-5
