7. Inspect the reverse gear bearing for roughness, catches, pits, or discoloration from lack of lubricant. If the bearing must be
replaced, use a torch lamp to warm the bearing carrier assembly to aid in removal. Remove the O‑ring from the carrier to
prevent heat damage. Use a bearing puller assembly to remove the bearing from the bearing carrier.
a - Torch lamp
b - Reverse gear bearing
c - Bearing puller
assembly
Bearing Puller Assembly 91‑ 83165T
Torch Lamp 91‑ 63209
8. Use a torch lamp to warm the outer surface of the bearing carrier where the carrier seal is located. Use a bearing puller
assembly to remove the carrier seal.
NOTE: When removing the carrier seal, do not scar the carrier seal surface. If the carrier seal surface is damaged, replace
the carrier.
a - Torch lamp
b - Bearing puller assembly
c - Oil seal
Bearing Puller Assembly 91‑ 83165T
Torch Lamp 91‑ 63209
Gear Housing (2.15:1)
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 6A-15
