Mercury 20 EFI FourStroke

4. Remove the propeller shaft from the reverse gear/bearing carrier assembly.
a - Reverse gear/bearing
carrier assembly
b - Thrust washer
c - Propeller shaft
5. Replace the reverse gear if the gear teeth or clutch teeth are chipped or worn.
a - Clutch teeth
b - Gear teeth
6. If the reverse gear must be replaced, use a bearing puller assembly to remove the reverse gear from the reverse gear
bearing.
a - Bearing carrier assembly
b - Reverse gear
c - Bearing puller assembly
Bearing Puller Assembly 91‑ 83165T
b
c
a
62932
b
a
34377
a
b
c
34379
Gear Housing (2.15:1)
Page 6A-14 © 2018 Mercury Marine 90-8M0125265 eng NOVEMBER 2017
