Tiller Handle Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Hex head screw
2 1 Pin
3 1 Socket head screw 24 – 17.7
4 1 Lower bracket
5 1 Toe clamp
6 2 Plain washer
7 1 Locknut 50.0 – 36.9
8 1 Rubber cap
9 2 Cable tie with anchor
10 1 Dowel pin
11 1 Tiller handle bracket
12 2 Throttle cable
13 1 Down stop adjustment screw
14 1 E‑ring
15 1 Tiller handle cover
16 1 Tiller operation decal
17 2 Cable tie
18 1 Shift handle assembly
19 2 Flange bushing
20 1 Shift lever assembly
21 1 Locknut 1.1 9.7 –
22 1 Hex head screw 20.3 180 –
23 1 Plug
24 1 Hex head cap screw
25 1 Belleville washer
26 1 Flange spacer
27 1 Shift cable
28 2 Pin
29 2 Tilt locking tab
30 2 Flange bearing
31 1 Spring
32 1 Pin
33 1 Tilt lever and shaft
34 1 Plug
35 1 Locknut 20.3 180 –
36 2 Flange bushing
37 1 Tiller handle chassis
38 1 Pad
39 6 Pan head screw 2.3 20.3 –
40 1 Spare clip decal
41 1 Lanyard cord assembly
42 1 Spare lanyard clip
43 2 Pan head screw 2.3 20.3 –
44 1 Flat spring shift detent
45 1 2‑pin male connector (for stop switch assembly)
46 1 Stop switch assembly (without connector)
Tiller Handle
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 7B-5
