Mercury 200 EFI User Manual

FUEL PUMP
90-883728 JULY 2001 Page 3A-5
Fuel Pump Assembly
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 FUEL PUMP ASSEMBLY
2 1 BODY–FUEL PUMP
3 2 CHECK VALVE
4 2 RETAINER
5 1 SPRING
6 1 CAP
7 1 SPRING
8 1 CAP
9 2 DIAPHRAGM
10 1 GASKET
11 1 GASKET-BOOST
12 1 GASKET-PULSE
13 1 PLATE
14 2 SCREW–FUEL PUMP (M5 x 40) 55 6.0
15 2 SCREW–PUMP TO CRANKCASE (M6 x 50) 55 6.0
16 1 BASE
17 1 ELBOW
18 1 FITTING
19 1 ELBOW (45 DEGREE)
20 2 STA STRAP
21 1 TUBING (6 IN.)
22 1 ELBOW
