Mercury 200 EFI

POWERHEAD
Page 4A-56 90-883728 JULY 2001
6. Lubricate crankshaft ends (oil seal areas) with light oil, then install upper and lower end
caps (“a” and “b”). Secure end caps to cylinder block with attaching bolts. DO NOT tight-
en end cap bolts at this time.
51848
a
51848
a
14
14
14
2 Cycle Outboard Oil
c
b
a-Dowel Pin
b-Upper End Cap
c-Lower End Cap
