POWERHEAD
Page 4A-80 90-883728 JULY 2001
15. Install harness retainer and secure with 2 screws.
57841
a
a
b
a-Screws
b-Retainer
16. Slide outboard shift lever into neutral position.
17. Install throttle cable.
18. Install locknut that secures shift cable latch assembly and install latch, flat washer, nylon
wear plate, spring and shift cable from control cable anchor bracket.
57838
a
b
d
e
f
g
h
i
c
j
a-Lock Nut (Throttle
Cable)
b-Flat Washer
c-Shift Cable Latch
d-Lock Nut (Shift Cable)
e-Flat Washer (Hidden
under nut)
f-Nylon Wear Plate
g-Spring (Hidden)
h-Shift Cable
i-Anchor Bracket
j-Throttle Cable
Refer to Section 2 of this Service Manual “Timing/Synchronizing/Adjusting” for engine
set-up procedures.
