Mercury 200 EFI

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-883728 JULY 2001 Page 5A-5
Transom Brackets
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 TRANSOM BRACKET (STARBOARD)(BLACK)
2 1 TRANSOM BRACKET (PORT) (BLACK)
3 1 GREASE FITTING (PORT) 80 9
4 1 TILT TUBE
5 1 NUT (1 IN.-14) 45 61
6 1 O-RING
7 2 WAVE WASHER
8 1 NUT (7/8-14) 45 61
9 4 BOLT
10 4 WASHER
11 4 NUT
12 1 TILT LOCK LEVER ASSEMBLY
13 1 SPRING
14 2 BUSHING
15 1 SPRING
16 1 KNOB
17 1 GROOVE PIN
18 1 PIN
