POWER TRIM
90-883728 JULY 2001 Page 5B-5
Power Trim Components
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
– 1 POWER TRIM ASSEMBLY–Complete
1 1 MANIFOLD ASSEMBLY
2 9 PIPE PLUG
3 1 TILT CYLINDER ASSEMBLY
4 1 PISTON ROD
5 1 GUIDE KIT
6 1 REPAIR KIT
7 1 CHECK VALVE KIT
8 2 GUIDE ASSEMBLY
1 PISTON/ROD ASSEMBLY (PORT)
9
1 PISTON/ROD ASSEMBLY (STBD.)
10 1 TRIM FILTER ASSEMBLY
11 1 VALVE ASSEMBLY
12 1 E RING
13 1 O RING KIT
14 1 PUMP
15 1 PLUG ASSEMBLY
16 4 SCREW
17 4 WASHER
18 1 COVER
19 1 DRIVE SHAFT
20 1
TRIM MOTOR
(Breakdown on Power Trim Motor)
2 SCREW (LONG) 80 9
21
2 SCREW (SHORT) 80 9
22 1 SHAFT ASSEMBLY
23 2 PIPE PLUG
24 1 GROOVE PIN
25 1 GROOVE PIN
26 1 SHAFT
27 1 ANODE ASSEMBLY
28 2 SCREW (M6 x 1 x 25) 70 8
29 2 WASHER
30 6 SCREW (M10 x 1.5 x 30) 45 61
31 6 WASHER
32 1 DECAL-Caution power trim
33 1 SCREW (10-16 x 3/5 IN.)
34 1 C WASHER
35 2 CLAMP
36 1 TUBING
37 1 STA-STRAP
38 2 FILTER SCREENS
NOTE: Lubricate all o-rings with Power Trim and Steering Fluid.
