8
COLOR DIAGRAMS
Page 8-190-883728 MAY 2001
COLOR DIAGRAMS
Table of Contents
150/175/200 EFI 2002 Model Year
Wiring Diagram Page 8-3. . . . . . . . . . . . . . . . . . . . . . . .
Typical SmartCraft System Tachometer & System
Speedometer Installation with System Link Gauges
2002 Model Year Page 8-5. . . . . . . . . . . . . . . . . . . . . . .
Typical SmartCraft System Monitor/Tachometer
Installation with System Link Gauges
2002 Model Year Page 8-7. . . . . . . . . . . . . . . . . . . . . . .
Typical SmartCraft Dual Outboard Installation
2002 Model Year Page 8-9. . . . . . . . . . . . . . . . . . . . . . .
150/175/200 EFI 2002 Model Year
Oil & Fuel Flow Diagram Page 8-11. . . . . . . . . . . . . . . .
150/175/200 EFI 2002 Model Year
Water Flow Diagram Page 8-13. . . . . . . . . . . . . . . . . . . .
