Mercury 200 EFI

IGNITION
90-883728 JULY 2001 Page 2A-11
Electrical Plate Assembly
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 SOLENOID MOUNTING PLATE
2 3 SCREW (M6 x 10) 100 11.3
3 1 CLIP
4 3 RELAY
5 3 DECAL-TRIM RELAY
6 3 BRACKET
7 3 BUSHING
8 3 GROMMET
9 5 SCREW (M6 x 25) 35 4
10 1 BUSHING
11 1 TRIM HARNESS
12 1 CABLE (YELLOW/BLACK)
13 1 GROUND WIRE (BLACK)
14 2 BOOT (YELLOW)
15 1 INSULATOR BOOT (RED)
16 1 SOLENOID
17 2 GROMMET
18 2 BUSHING
19 1 CAP NUT
20 2 NUT (10-32)(BRASS) 8 0.9
21 2 LOCKWASHER
22 2 NUT (5/16-18) 50 5.5
23 1 WASHER
24 1 SCREW (M6 x 35) 35 4
25 1 ENGINE HARNESS
26 1 FUSE COVER
27 2 CLIP
28 1 HARNESS (FUEL INJECTOR)
29 1 HARNESS (TPS)
30 FUSE (4 – 20 AMP) (1 – 15 AMP)
31 AR STA-STRAP
32 3 SCREW (M6 x 12) 30 3.5
33 1 ECM
34 3 SCREW (M6 x 25) 70 8
35 3 BUSHING
36 3 GROMMET
37 3 WASHER
38 2 CLIP
39 2 SCREW (M6 x 14)
40 1 PLUG (MALE)
41 1 HARNESS-KNOCK SENSOR (200)
42 1 HARNESS-SMARTCRAFT
