CYLINDER HEAD
90-857138R1 MAY 2000 Page 4A-5
Cylinder Block
TORQUE
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 CYLINDER BLOCK
2 1 OIL SEAL
3 1 BALL BEARING
4 1 FILLER CAP
5 1 O RING
6 1 CAP
7 1 GASKET
8 2 BOLT 70 8
9 2 BREATHER TUBE
10 2 WASHER
11 1 TUBING
12 2 CLAMP
1 CYLINDER HEAD (4/5 H.P.)
13
1 CYLINDER HEAD (6 H.P.)
14 1 GASKET
15 2 DOWEL PIN
16 1 GASKET
17 1 THERMOSTAT COVER
18 1 GASKET
19 1 THERMOSTAT 126 degrees F (52 degrees C)
20 2 BOLT (M8 x 90 mm) 18 24.5
21 2 BOLT (M8 x 60 mm) 18 24.5
22 1 SPARK PLUG (NGK#DCPR6E) 13 17.5
23 1 COVER
24 1 GASKET
25 4 BOLT (M6 x 20 mm) 70 8
26 4 WASHER
– 1 GASKET SET
– 1 POWERHEAD (4 H.P.)
– 1 POWERHEAD (5 H.P.)
– 1 POWERHEAD (6 H.P.)
