CYLINDER HEAD

Page 4A-12 90-857138R1 MAY 2000

4. Place a rag under the cylinder head to support the valves. Using a suitable box end

wrench, depress valve spring to release valve keepers. Remove keepers (2), valve

spring retainer, valve spring and valve spring seat.

57338

a-Box End Wrench

b-Rag

57246

a-Keepers (2) per Valve

b-Valve Spring Retainer

c-Valve Spring

d-Valve Spring Seat
