Mercury 4 SERIES

CYLINDER BLOCK AND CRANKCASE
90-857138R1 MAY 2000 Page 4B–15
4. Remove the 9 bolts that fasten the oil pan to the cylinder block and cylinder head.
5. Break the oil pan seal. Pry up the oil pan at pry tab and in the open space beneath the
oil pan.
a
b
c
a-Oil Pan
b-Pry Tab
c-Pry Location Beneath the Oil Pan
6. Remove the oil pan.
