Mercury 4 SERIES

IGNITION SYSTEM
90-857138R1 MAY 2000 Page 2A-5
Electrical Components
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 NUT 40 54
2 1 WASHER
3 1 FLYWHEEL
4 1 CLAMP
5 1 SCREW Drive Tight
6 1 EXCITER COIL
7 2 SCREW 14 1.5
8 1 IGNITION COIL
9 1 BOOT
10 2 BOLT (M6 x 20mm) 70 8
11 1 REAR DAMPER
12
1 CD UNIT (4/5 H.P.)
12
1 CD UNIT (6 H.P.)
13 1 FRONT DAMPER
14 1 SLEEVE
15 1 CLAMP
16 1 SCREW Drive Tight
17 1 WARNING LAMP
18 1 STOP SWITCH
19 1 LANYARD
20 1 GROMMET
21 1 PULSER COIL
22 2 SCREW Drive Tight
