GENERAL INFORMATION
26
40/50 Specifications (Include English Units)
Model 40/50MH 40/50EH 40/50EHO
Overall length 1,143 mm
Overall width 384 mm
Overall height S = 1,225 mm, L = 1,352 mm, UL = 1,479 mm
Transom height S = 403 mm, L = 530 mm, UL = 657 mm
Weight
S = 72.0, L = 73.5,
UL = 75.0 kg
L = 78.5 kg
L = 80.0, UL = 81.5
kg
Maximum output 40 = 29.4 kW, 50 = 36.8 kW
Full throttle RPM 40 = 5000–5700, 50 = 5150–5850
Number of
cylinders
3
Displacement 697 mL
Bore and stroke 68 x 64 mm
Exhaust system Through hub exhaust
Lubrication Premixed fuel Oil injection
Fuel mixing ratio 50:1 120:1–50:1
Cooling system Thermostat controlled
Starting system Manual Electric (with manual backup)
Ignition CDI
Spark plugs
40: NGK B7HS‑10/BR7HS‑10 or Champion L‑82C/
RL‑82C (1.0 mm gap), 50: NGK B8HS‑10/BR8HS‑10 or
Champion L‑78C/RL‑78C (1.0 mm gap)
Alternator 12 V,130 W (12 V, 11 A)
Trim system Manual, 6 position
Engine oil Mercury or Quicksilver oil or recommended oil (TC‑W3)
Gear oil
Mercury or Quicksilver gear oil or API GL5, SAE #80 to
#90, approximately 500 mL
Fuel tank capacity 25 L (6.6 US gal)
Engine oil capacity –
Approximately 2.0 L
(0.53 US gal)
Gear reduction ratio 13:24
Fuel
Unleaded regular gasoline pump posted 87 octane
(research octane rating of 91)
To Next Page
