Mercury 40/50 Series User Manual

INSTALLATION
45
Power trim and tilt model: EHPTO, EPTO
a - Washer (smaller diameter)
b - Bolt (M12 x 105 mm)
c - Top of transom
d - Washer (larger diameter)
e - Nut
NOTE: We recommend the bolt head of the upper bolts face inward
while the nuts are kept on the outside of the boat to prevent injury
to the passengers.
1. Apply sealing agent, such as silicon sealer, between the bolts
and the boat transom holes when tightening the bolt.
2. Secure the engine tightly with the bolts.
38306
a
b
d
e
c
(4.24)
13
13
125.5
251(9.87)
158(6.22)
30
(4.24)
125.5
173
(6.81)
158(6.22)
316(12.44)
327(12.87)
163.5(6.44)163.5(6.44)
18(0.7)
18(0.7)
18(0.7)
(1.18)
56(2.2)
310(12.2)
254(10)
51(2)
69(2.72)
87(3.43)
105(4.13)
(0.51)
